The Korg CA-40 Compact, LCD Needle Style Chromatic Tuner is a compact chromatic tuner, ideal for use with brass band or orchestra.

The Korg CA40 Compact, LCD Needle Style Chromatic Tuner has a wide range that covers A0 (27.50 Hz) ? C8 (4186.01Hz), you can tune a variety of instruments with the CA-40, including wind, string, and keyboard instruments. The pitch and range are detected quickly and accurately. You can use the built-in high-sensitivity microphone to detect the pitch of an acoustic instrument without requiring any other equipment. Alternatively, you can use the separately sold CM-100 contact microphone to send the vibration of the instrument directly to the tuner, so that you can tune accurately without worrying about other sounds in the environment. An output jack (bypass) has been added, making it easy to check the tuning even while you perform.

The Korg CA-40's display has been enlarged for even better visibility. In addition to providing both the accuracy of an LCD and the easy viewing of a needle-style meter, red and green LEDs are also provided to indicate pitch deviations, making tuning smooth and easy.

The Korg CA-40 Compact, LCD Needle Style Chromatic Tuner Main Features Include:

• A compact chromatic tuner, ideal for use with brass band or orchestra.
• Larger and more easily readable high-precision LCD needle-style meter.
• Wide detection range from A0~C8.
• Calibration function that accommodates a variety of concert pitches.
• Sound Out function that lets you produce a reference tone from the internal speaker. The tuner will remember the pitch you select.
• Bypass function.
• Auto Power Off function saves the battery even if you forget to turn off the tuner.
• Memory Backup function.
• Approximately 85 hours of continuous use.
• Scale: 12-note equal temperament
• Detection Range : A0 (27.50 Hz) - C8 (4186.01 Hz): for a sine wave
• Reference Tone: C4 (261.63 Hz) - C5 (523.25 Hz): 1 octave
• Tuning Mode: Meter mode (AUTO), Sound Out mode (MANUAL)
• Calibration Range : A4=410 Hz - 480 Hz (1 Hz steps)
• Detection Accuracy: ±1 cents or better
• Tone Accuracy: ±1.5 cents or better
• Connectors: INPUT jack (1/4" monaural phone jack)
• Power Supply: two AAA batteries (3V)
• Dimensions: 100 (W) x 67 (D) x 17 (H) mm / 3.94" (W) x 2.64" (D) x 0.67" (H)
• Weight: 88 g / 0.19 lbs.
