      The Manley Reference Cardioid Microphone shares the same electronic attributes as the Gold Reference Series, but has a centre- ...
      Množství :
      Napište svou recenzi

      EU3234363840424446USXX5XSSMLXLXXLXXLArm Length6161,56262,56363,56464,5Bust Circumference8084889296101106111Waist Girth6165697377828792Hip Circumference87919599103108113118

      • Doprava zdarma na tisíce položekDoprava zdarma na tisíce položek
      • 100% bezpečné online platby100% bezpečné online platby
      • 30 dní možnost vrátit zboží30 dní možnost vrátit zboží

      The Manley Reference Cardioid Microphone shares the same electronic attributes as the Gold Reference Series, but has a centre- fixed cardioid-only capsule with a thicker gauge (6 micron) gold sputtered diaphragm. With the similar film thickness and construction, similar high frequency resonance (a little edge), similar proximity effect and pretty good immunity from pops and sibilance problems, the Reference Cardioid more closely recalls how many of the vintage European tube mics such as the beloved U47 sounded like when they were new. Its rich tonal balance and liquid character is consistently admired for instruments such as guitars, drum overheads, saxophone, and especially vocals. With your present mic, if you find yourself leaning on your compressors and boosting 5 or 10K to score a bit more testosterone, then the Reference Cardioid just might be the mic youre looking for. If you seem to be constantly boosting 12-18K and trying to get a clean, intimate sound, then probably the Reference Gold would be the safest bet.

      Features:

      • All-Tube triode design
      • -10 dB switchable pad
      • Frequency response: 10Hz - 30KHz
      • Low Noise - typically - 120dB EIN
      • High Max SPL: 150dB

      Specifications:

      • Microphone type: Dual large diaphragm capacitor
      • Polar patterns: Fixed Cardioid
      • Diaphragm size: 1 inch ; 1.25 inch overall
      • Diaphragm thickness: 3 micron; gold sputtered
      • Frequency response 10 hz to 30 khz, amplifier to 60 khz
      • Maximum input spl: 150 dbspl at capsule
      • Sensitivity: 19mv/pa
      • Amplifier type: 2 triode gain block lo z output
      • Active components 1) 12ax7lps tube (2 for stereo mics)
      • Output type : transformer with feedback loop
      • Output polarity: balanced xlr, pin 2 hot, pin 3 low
      • Amplifier distortion: less than .05 %
      • Amplifier noise: typically -120 db ein (tube dependent)
      • Body: 24 karat gold over machined brass
      Manley
      REC0008595-000

      Parametry

      Manufacturer
      Manley
      Weight (kg)
      1.02
      Colour
      Black
      Width (mm)
      114
      Height (mm)
      114
      Depth (mm)
      246
      Application Area
      Vocal/Speech
      Microphone type
      True condenser
      Input
      XLR 3 Pol
      Frequency range
      10 Hz - 30 kHz
      Sensitivity (mV/Pa @ 1kHz)
      17
      Capsule size
      Small
      Mono or stereo
      Mono
      Power supply
      External
      Maximum SPL in dB
      150
      incl. Accessories
      Shock mount
      Polar Pattern
      Cardioid
      Tube type
      ECC83 12AX7
