• Suitable for small to medium-sized systems
• Class D amplifier with 240W output power for standard stereo speakers or high-impedance speakers
• Bluetooth (antenna can be extended)
• Integrated mixing function with controls
• Ducking function
• Two-band EQ and high-pass filter
• Output with mono/stereo switching
• Compact half-rack design
• Optional accessories available:
  • AK-RM05 rack mounting kit
  • Controller for remote control of the overall volume

Connections:

• Microphone/line inputs (MIC/LINE IN):
  • Front: XLR/TRS combo socket (balanced)

  • Rear: 4-pin Euroblock connector (balanced, 3.81 mm pitch)
• Line inputs (LINE IN 1 / LINE IN 2):

  • RCA sockets (unbalanced)
• Line output (LINE OUT):

  • RCA sockets (unbalanced)
• High impedance output:

  • 2-pin Euroblock connector (pitch 5.08 mm)

• Audio performance:
  • Frequency response: 20 Hz to 20 kHz +/-2 dB
  • Distortion: 0.05% or less
  • S/N ratio: 92 dB or more
  • Crosstalk: 70 dB or more
• Speaker outputs:
  • High impedance operation:
    • Rated output power 240 W, single channel (70 V / 100 V)
    • Total impedance: At 100 volt output voltage (100V) ≥42 Ω, at 70 volt output voltage (70V) ≥21 Ω
  • Low impedance operation:
    • Nominal output power: 2 × 120 W (4 Ω or 8 Ω, 1 kHz, 1 % THD)
    • Load impedance: 4 Ω / 8 Ω (selectable)

• Inputs:
  • Microphone/line inputs:
    • MIC switch position:
      • Maximum input level: -30 dBu
      • Minimum input level: -65 dBu
      • Input impedance: ≥2 kΩ
    • Switch position LINE:
      • Maximum input level: +20 dBu
      • Nominal input level: +4 dBu
      • Input impedance: ≥10 kΩ
  • Line inputs (LINE IN 1 / LINE IN 2):
    • Maximum input level: +6 dBV
    • Nominal input level: -10 dBV
    • Input impedance: ≥10 kΩ
