• Bass Synthesizer
• Desktop format
• Monophonic
• Analogue sound generation
• 1 oscillator (sawtooth / square with PWM)
• 2 sub oscillators (-1 oct. & -2 oct.)
• Glide
• 18dB OTA Lowpass filter
• OTA distortion
• OTA VCA
• LFO with triangle waveform
• ADSR envelope for filter
• A/R envelope for VCA
• 9 CV/Gate inputs & outputs
• Can be used standalone or as Eurorack module (42 TE)
• incl. ribbon cable & MIDI-TRS adapter

A construction kit for basslines

The structure of the Hades consists of an oscillator with sawtooth and square waveform including pulse width modulation. The oscillator is followed by two level-adjustable sub-oscillators, calibrated to -1 and -2 octaves. The filter is a resonant 18dB Lowpass filter; 303 moments are less to be expected here, but it sounds extremely creamy and somewhat fuzzy. The filter is followed by a powerful distortion element whose spectrum ranges from slightly warming up to overdriving the signal. The last element is a fast reacting VCA. Filter, distortion and VCA are based on OTA circuits, which sonically goes in the direction of old Roland synthesizers and is generally perceived as very musical.

Punchy Basslines & FM Alarm

The modulation section consists of an A/R envelope for the VCA, a slightly percussive ADS(R) for the filter and a free LFO with triangle waveform, whose time range goes from about 10 min to 3000 Hz. If you include the control voltage inputs and outputs, you get new sounds that would not be possible without the patch jacks. Keytracking for the filter, PWM in the audio section and wobbling tremolo effects with the VCA are only a part of the possible patches.
