Other features

• Hassle-free, latency-free monitoring
• Switch between computer output and direct signal with a single button press
• Ideal for recording overdubs alongside a previously recorded track
• 3-band EQ on all channels with variable mid-frequency control (channels 15/16 have standard 3-band EQ).
• Channels 9-14 have mic inputs and stereo line inputs for maximum versatility
• Hi-Z switches allow direct connection of guitars, basses and other instruments.
• 100Hz low-pass filter and 48V phantom power on all mic channels
• Stereo 1/8" input on channel 15/16
• 3 aux/monitor outputs with dedicated sends per channel
• Two stereo subgroups with assignment per channel
• Headphone output with separate level and blend controls
• Dedicated control room output with level control
• Inserts on channels 1-8
• Pre-fader solo on all channels
• Footswitch connection for muting the FX engine
• Easy compression via a single pot for maximum headroom
• Ideal for putting the finishing touches on vocals in live, recording, and even streaming applications
• Includes ProTools® | First and Waveform™ with comprehensive plug-in bundles for instant professional recordings
• The Musician Collection for ProTools | First includes 23 plug-ins such as BBD Delay, Gray Compressor and Eleven Lite
• The DAW Essentials™ bundle for Waveform™ OEM includes 16 powerful plugins such as Equalizer, Compressor, Reverber8 and Limiter
• Legendary Mackie "Built-Like-A-Tank" design.
• Solid steel chassis protects the mixing console
• Rugged ABS side protection
• Mute buttons light up when activated

• iOS support for iPhone and iPad (original Apple Camera Kit Adapter required!!!)


Technical Specifications

• 11 mic inputs with 3-band EQ on all channels with variable mid-frequency control (channel 15/16 has standard 3-band EQ)
• 8 inserts and 8 single-knob compressors
• channels 9-14 have microphone inputs and stereo line inputs
• 1 x 3.5 mm stereo jack input
• 2 x 4 USB interface
• built-in GigFX effects unit with 24 effects
• 100 Hz low cut filter
• 2 Hi-Z switches
• 48 V phantom power
• Headphone jack
• 3 aux/monitor outputs with dedicated sends per channel
• 2 stereo subgroups with dedicated sends per channel
• Footswitch connector
• Dimensions (H x W x D): 112 × 450 × 434 mm
• Weight: 6.9 kg
