• HEDD AMT tweeter

• Absolutely phase-faithful reproduction

• High resolution of the stereo image

• Excellent depth staggering

• AD/DA conversion maximum: 96kHz / 32Bit

• Crossover frequency 2.3kHz (48dB/oct)

• Input gain +/- 12dB

• Integrated lineariser

• Latency with activated HEDD Lineariser 10ms
• Shelf Filter Low/High: ±4 dB
• Desk Filter 180Hz (-1/ -2/ -3/ -4dB)
• Power amplifier output: 2x 100W
• CoP technology (Closed or Ported)


Absolutely true to phase!

In addition to many adjustment possibilities in the frequency range, HEDD has also thought about the problems in the phase position, which are inherent in every speaker. Thus, the experience already gained with the HEDD Lineariser plug-in has been used and firmly implemented in the studio monitors. On the digital level, the loudspeaker-specific nonlinearities in the phase position are corrected and thus an absolutely phase-true reproduction is guaranteed. The user is free to decide whether to use the linearizer or not. On the back of the HEDD Type 07 Mk2 speaker, it can be deactivated if necessary. This is especially useful when recording, since an activated linearizer results in a playback latency of 10-20ms, which could disturb the musician while playing.

Bass reflex or closed? Both, please!

The closable bass reflex tube takes away the decision for one of the two speaker systems. With the included foam plug, the monitor can be closed off and turned into a closed speaker in no time at all. A "CoP" (Closed or Ported) switch on the rear panel allows you to adjust the DSP to the setup you choose.
