• 16 AES/EBU channels with 24 bit / 192 kHz
• Internal Clock with '1 ns jitter
• Switchable sample rate converter (SRC)
• DSP mixer with 64 channels and parametric EQs
• Cascadable via TDM SyncBus
• Word clock and super clock input
• Word clock and superclock output
• Two MIDI inputs and outputs
• Expansion card for flexible installation
• ASIO support for DAW integration
• Compatible with Thunderbolt PCIe adapters
• Windows drivers and lifetime support

Extended synchronisation and MIDI connectivity

In addition to a word clock and superclock input, the Clara D+ has an additional word clock and superclock output. Two MIDI inputs and outputs allow the integration of external MIDI devices. All expansions are provided via a supplied expansion card, which is connected to the sound card via a ribbon cable and can be placed versatile in the computer housing.

DSP mixer with real-time routing

The integrated DSP mixer enables latency-free routing and mixing of up to 64 input signals, which can be mixed to 8 sums and sent to any output. DAW playback signals can be seamlessly integrated and all mix sums can be sent back to software for recording. Four parametric EQs per channel allow for targeted sound processing.

Switchable SRC for seamless integration

The software-switchable sample rate converters (SRC) allow digital input signals to be processed independently of their original sample rate and clock setting. This allows digital devices to be connected without separate synchronisation lines.

Scalability and system cascading

Using the TDM SyncBus, several Clara D+ systems can be combined in one computer and presented as a single sound system to an ASIO application. Up to 32 audio signals can be exchanged within the Beast Mixer with other Clara systems and can be integrated into the workflow.

Compatibility and driver support

The Clara D+ is compatible with common Thunderbolt PCIe adapters and offers driver support for Windows. Lifetime quality support ensures that the system can be used reliably over the long term.

Technical data:

• PCIe audio interface
• 1 lane (PCIe 1x) according to PCI Express Base Specification 2.1
• PCIe Busmaster DMA with Direct ASIO Support
• Sample rates from 22 to 192 kHz
• Sample resolution from 8 to 32 bits for audio application
• Switchable input SRCs with 144 dB(A) dynamic range and 1:16/16:1 conversion
• Beast DSP powered
• 64 freely configurable DSP channels: Input, TDM and playback signals
• TDM SyncBus
• Multi-Card support
• Wordclock / Superclock input
• BNC input frequency range: 0 to 30 MHz
• BNC input impedance: 5 kOhm, software-controlled termination to 75 Ohm
• BNC input voltage range: 1.5 Vpp to 5.0 Vpp
• BNC input: DC offset free, Schmitt-triggered, overvoltage protection
• Clock jitter '1 ns
• Synchronization sources: Internal, WordClock/Superclock, AES/EBU; TDM SyncBus

Digital inputs:

• 4 AES/EBU (8 channels)
• Up to 32 channels via TDM SyncBus
• BNC WordClock
• 2x MIDI

Digital outputs:

• 4 AES/EBU (8 channels)
• Up to 32 channels via TDM SyncBus
• BNC WordClock
• 2x MIDI
