• PCIe card for compact systems (low profile server, mini & media housings)
• 24 bit / 192 kHz resolution (digital connections)
• 32 bit / 384 kHz resolution (analog connections)
• 1 AES/EBU input and output (4 channels)
• 2 analog inputs and outputs (4 channels)
• 2 MIDI inputs and outputs ("+" version)
• Automatic shutdown of the outputs when the computer is started
• Balanced XLR connections

• Switchable input SRCs with 144 dB dynamic range

• Beast DSP mixer with EQ

• Cascadable via TDM SyncBus

• Compatible with common Thunderbolt PCIe adapters

• Wordclock / Superclock input and output

• Windows driver


Analog and digital excellence

With a dynamic range of 128 dB, the Clara B's analog connections are top class. The 32-bit AD/DA converters in the precisely tuned analog circuitry guarantee outstanding sound quality. A maximum level of up to +24 dBu ensures that all connected devices receive sufficient signal and headroom.

Switchable sample rate converter (SRC)

The software-activated SRCs make it possible to integrate any digital input signal into the sound system, regardless of sample rate and clock settings. This ensures problem-free connection of all digital devices without separate synchronization lines.

Sound system with the +

The "+" variant includes an extension with word clock inputs and outputs as well as two MIDI inputs and outputs. This expansion card is connected to the sound card via a ribbon cable and can be placed versatile in one of the slots of the computer housing.

Fast and reliable multi-client driver suite

The continuously evolving driver offers multi-client support for ASIO 2.2 and multi-channel WDM audio/WASAPI with minimal latency in all software environments. This allows multiple audio applications to access the sound system simultaneously, whether via the same or different driver interfaces.
