• Hybrid Synthesizer
• Desktop housing
• 16 velocity-sensitive pads
• Algorithmic Engine (7 oscillator modes)
• 16 voices
• 8 oscillators
• over 300 waveforms
• analog 24dB Lowpass filter
• digital Multimode filter with 18 types
• Effects: 9 inserts / 5 delays / 4 reverbs
• LFOs: 5 per voice
• Envelopes: 1 per oscillator + 5 per voice
• Modulation matrix with 32 slots
• Randomizer
• 1024 presets
• 640 Multimode presets
• Programmable arpeggiator
• step sequencer
• 8 macro controllers
• ribbon controller
• illuminated pitch and modulation wheels
• full MIDI implementation including MPE
• 2 CV inputs
• CV, Gate, Mod 1 & 2 & c lock control voltage outputs
• MIDI In/Out/Thru
• Mono/stereo audio outputs
• Pedal inputs for Sustain & Expression
• USB MIDI
• incl. a pair of rack ears for mounting in 19" racks

Digital & Analog Filters

The two filters form the heart of the hybrid synthesis architecture. First, the digital Multimode filter offers 18 types, including unique models like low-pass, band-pass, high-pass, notch, vintage classics, and even a vocal filter (Vowel). This is followed by an analog 24dB Lowpass filter with built-in overdrive. The overdrive adds a subtle punch to the sound, giving oscillator mixes, especially with classic waveforms, a lot more bite. The analog filter really enhances the overall tone.

The Sound Construction Kit With Endless Potential

With the oscillator section, ASM has given the Leviasynth a major selling point. The eight oscillators can be arranged in "algorithms" that define how they interact. There are 144 preset algorithms to choose from, and you can create a custom algorithm for each patch. Additionally, Algorithm Morph gives you the freedom to create almost any oscillator configuration. Over 300 waveforms and 7 independent oscillator modes are available for each oscillator, providing endless sonic possibilities. FM setups, oscillator sync, and noise also form part of the palette. In short, there's much more here than just a few oscillators waiting to be adjusted.

A Modulation Wonderland

When it comes to modulation, the Leviasynth truly delivers. It offers five LFOs and five envelopes for each voice; there are even eight separate envelopes dedicated to the eight oscillators. Plus, there's an extensive modulation matrix with 32 slots and a randomizer. Modulation sources are available via the display and include eight macro controllers, a large ribbon controller, two control voltage inputs, illuminated handwheels for pitch bend and modulation, and the keyboard itself. In addition to pitch and note length, the keyboard generates velocity and polyphonic aftertouch. These extensive modulation options are rounded out with a full MIDI implementation, including MPE (MIDI Polyphonic Expression).

Effects

At the final stage of the signal chain, there are three effect blocks to add the finishing touch to your sound. Modulation effects like chorus, flanger, rotary, phaser, and tremolo, plus sound enhancers such as EQ, lo-fi, compressor, and distortion, are available as insert effects. Delay and reverb can be used simultaneously, with five variations of delay and four for reverb, offering you a wealth of creative options.
