4ms MetaModule Audio Expander
153,85 €
TAXĂ INCLUSĂ
Expander, expansion module, 4ms MetaModule, audio, CV, 6 inputs, 8 outputs, signal depth 24 bit / 48kHz
Livrare gratuită pentru mii de articole
Plăți online 100% sigure
30 de zile disponibile pentru returnarea bunurilor
Audio/CV Expander for the MetaModule
- Audio/CV extension for MetaModules
- 8 CV/audio outputs
- 6 CV/audio inputs
- Signal depth 24 bit / 48kHz
- Voltage range +/- 10 V
- incl. ribbon cable for connection to the MetaModule
4ms MetaModule Audio Expander at a glance
The MetaModule Audio Expander expands the 4ms MetaModule with an additional 6 CV/audio inputs and 8 CV/audio outputs. The expansion module is connected to the MetaModule at the rear using the ribbon cable supplied. The task respectively assignment of the respective sockets can be saved individually in each Patch . The DC-coupled signal converters offer the same high quality as the audio/CV sockets of the MetaModule, which have a signal depth of 24 bit / 48kHz. The voltage range is +/- 10 volts on the input and output side.
SYN0009219-000
Fisa tehnica
- Depth (mm)
- 32
- + 12 V (mA)
- 140
- - 12 V (mA)
- 25
- TE / HP
- 6
- Passive
- No
- Manufacturer
- 4ms
